Engineers develop networked self-analyzing electric motors

A team of engineers from Saarland University in Germany is developing intelligent motor systems that function without the need for additional sensors. By essentially transforming the motor itself into a sensor, the team, led by Professor Matthias Nienhaus, is creating smart motors that can tell whether they are still running smoothly, can communicate and interact with other motors, and can be efficiently controlled.

Simply using magnetic-field data collected from the motor while it is operating, the researchers are able to calculate quantities that in other systems would need to be measured by additional sensors -- and they are teaching the drive how to make use of this knowledge.

By transforming the motor itself into a sensor, a team led by Professor Matthias Nienhaus is creating smart motors. [Credit: Oliver Dietze]





They are currently working with project partners to study and test a number of different procedural methods. The ultimate goal is to make manufacturing processes more cost effective and flexible and to enable machinery and equipment to be continuously monitored for faults or signs of wear.

The project will be highlighted at the huge HANNOVER MESSE trade show in Germany from April 25-29, where the team will be exhibiting at the Saarland Research and Innovation Stand in Hall 2, Stand B46.

Sensors are all around us in today's world. Cars, for example, contain dozens of these tiny artificial sentient devices that warn us when, for instance, something gets too close to the vehicle, when the coolant gets too hot, or when there is too little fuel in the tank. But these small, sensitive detectors can sometimes fail and stop working, with the result that the vehicle is left standing at the side of the road. And what can happen to a car can also happen to other machines or pieces of plant equipment: A faulty sensor can lead to production downtimes and financial losses.

Professor Nienhaus, a drive systems specialist, is working on developing a new kind of self-monitoring motor -- one that doesn't need sensors. "We're developing an important new type of sensor -- the motor itself," says Nienhaus. The advantage of this new approach is that the engineers simply collect data that is available from the normal operation of the motor. "That makes our approach very cost effective, as there's no need to install any additional sensors," he says. "We're looking at elegant ways of extracting data from the motor and of using this data for motor control and for monitoring and managing processes. We are also working with project partners on improving the design and construction of miniature motors so that they yield the greatest possible quantity of operational information." His specialist area of research concerns electromagnetic miniature and microdrive systems with power ratings ranging from a tenth of a watt to several hundred watts.

Just like a doctor uses blood test data to draw conclusions about the health of a patient, Nienhaus and his team use motor data to determine the health of a drive system.

In order to gather data from the motor, Nienhaus and his team carefully monitor the precise distribution of the magnetic field strength in the motor. An electromagnetic field is generated when electric current flows through the coils located within the outer ring of rotating permanent magnets. The researchers record how this magnetic field changes when the motor rotates. This data can then be used to compute the position of the rotor and to draw other inferences about the status of the motor, which allows the motor to be controlled efficiently and error states to be detected reliably.

"We examine how our measured data correlates with specific motor states and how specific measured quantities change when the motor is not operating as it should," says Nienhaus. Gathering data from the motor while it is operating normally is particularly valuable for the research team; the more motor data they have, the more efficiently they can control the motor. The engineers analyze the huge amount of motor data in order to identify those signal patterns that can be used to infer something about the current status of the motor or to flag changes arising from a malfunction or from wear. The team is developing mathematical models that simulate the various motor states, fault levels, and degrees of wear.

The results are fed into a microcontroller, the brain of the system that processes the data. If a certain signal changes, the controller can identify the underlying fault or error and respond accordingly. These "sentient" motors can be linked together via a network operating system to form an integrated complex that opens up numerous opportunities in the fields of maintenance, quality assurance, and production. It is also conceivable that a system could be designed in which one motor automatically takes over if one of the other motors fails.

Nienhaus is currently testing a number of different methodologies to determine those best suited to acquiring data from the motor. He is also looking to identify which motor speed range generates the best data and which type of motor is best suited for this type of application.

This work is being carried out as part of a multi-partner industry project called "Modular sensor systems for real-time process control and smart state monitoring" (MoSeS-Pro), whose members include companies such as Bosch, Festo, Sensitec, Pollmeier, CANWAY, and Lenord, Bauer & Co. The goal of the research project is to develop a suite of hardware and software modules with which it will be easier to develop sensor systems for monitoring and controlling drives and positioning systems, paving the way for fast and precise manufacturing processes that can be monitored and adjusted in real time.

Application example: Smart conveyor rollers
Conveyor systems are used in many different places: mail-order firms, parcel delivery services, factories, and airports, to name but a few. To improve the speed and reliability with which goods are transported to their destinations, engineers at Saarland University are currently developing smart conveyor rollers that communicate with one another by turning the motor inside every drive roller into a sensor. When the conveyor is running, the drive motors continuously generate data, which allows the rollers to be precisely controlled and thus respond to changing operating conditions. These intelligent roller conveyor systems can identify new routes if a fault arises or can flag certain conditions, such as when there is space in a box for more cans. The project partners intend to test the system at a large distribution center.

Professor Nienhaus' conveyor system under development does not require any additional sensors, such as position sensors, so it is remarkably inexpensive. There is also no risk of sensitive (extra) sensors becoming damaged or unable to generate a signal for some reason.

If one of the rollers is not rotating properly because the bearing is worn, or if a short circuit has knocked out one of the coils, the magnetic field generated by the motor will change and this will be immediately registered by the system.

"The data we gather enables us to detect even very small changes," says Nienhaus.

The system is able to detect any deterioration in the performance of a roller early on. The engineers perform calculations and experiments to determine how the measurement data correlates with specific motor states. The results are stored in the system's "brain" -- a microcontroller that processes the data in real time.

The thousands of individual rollers in the roller conveyor system interact with one another via the network operating system that is integrated into each roller. The rollers can communicate with each other and can therefore respond flexibly whenever an unexpected condition arises. Unlike conveyor systems with a centralized external controller, each conveyor roller "knows" by itself how to respond at any given time. This makes it possible to build roller conveyor systems that can do new things.

"By analyzing angular momentum data, we can draw conclusions about the weight of a box currently being transported and decide whether or not another package could be added to the box," says Nienhaus. The system could then make fulfillment and transport decisions on its own. He and his team are also working on ways to make the data even more reliable by computationally filtering out artifacts and interference effects.

Source: Laboratory of Actuation Technology, Saarland University, Saarbrücken, Germany

Published April 2016
